Knuckle Boom Crane

Model:

SQZ330

Boom Length (m):

16.37(m)

Crane deadweight (Kg):

5100(Kg):

Feature Introduction

The luffing mechanism adopts a linkage design, which is compact and improves the lifting torque.
The double-chamber, wide-span outrigger structure provides better operational stability.
Finite element analysis is used for product structure optimization, resulting in a lighter overall machine weight.
The rotary reducer drives the rotation, enabling continuous 360° rotation.

a.can be customized boom section, an option 2-6;

b.crane color can be customized;

c. attachment can be added;

Hydraulic Parameters

nodata
