Knuckle Boom Crane

Crane overall Introduction

Crane model: GSQZ760.8 XCMG brand knuckle boom crane, Max. lifting capacity 38000Kg, 8 telescopic boom working radius 20.55 meters. 360 degree rotation.

XCMG crane 38Ton knuckle boom crane, suitable for chassis tractor head, trailer truck

XCMG Crane Feature

1. New hexagonal boom cross-section: Greater lifting capacity with the same boom radius, and stronger resistance to bending and torsion.

2. Regenerative control and a new sequential telescopic control system reduce boom extension pressure loss, improving load-bearing extension capacity and overall machine efficiency.

3. Rotatable and automatically tilting dual-stage, dual-cylinder outriggers: Improves chassis adaptability, provides a larger span, and enhances overall machine stability.

4. Multiple control options: upper and lower vehicle operation, and high-position turntable seat operation, meeting diverse customer needs.

5. Dual-reducer drive for slewing: Slewing motion is smoother and more powerful, with better braking performance.

6. Upper vehicle hydraulic proportional valve: Excellent micro-motion performance and capable of compound actions, providing high operating comfort.

7. Standard high-power radiator: Ensures the crane's oil temperature does not overheat during long-term heavy-load operation.

Advantages
